| Power requirements |
AC 100 ~ 120V/200 ~ 240V, 50/60Hz |
| Power consumption Starting |
73W |
| Power consumption Standby |
20W |
| Power consumption Unlock |
63W |
| Working temperature |
-28C ~ 60C |
| Working humidity |
5%-80% |
| Working environment |
Indoor/Outdoor(if sheltered) |
| Speed of throughput RFID |
Maximum 30/minute |
| Speed of throughput Fingerprint |
Maximum 25/minute |
| Lane width(mm) |
520 |
| Footprint(mm*mm) |
1120*1355 |
| Dimensions(mm) |
L=1120, W=315, H=985 |
| Dimension with packing(mm) |
L=1200, W=440, H=1080 |
| Lane width(mm) |
465 |
| Footprint(mm*mm) |
1200*765 |
| Dimension(mm) |
L=1200, W=300, H=1010 |
| Dimension with packing(mm) |
L=1310, W=420, H=1100 |
| Cabinet material |
SUS304 Stainless Stee |
| Net weight(kg) |
60 |
| Weight with packing(kg) |
65 |
| Cabinet material |
SUS304 Stainless Steel |
| Lid material |
Tempered Glass |
| Barrier material |
SUS304 Stainless Stee |
| Barrier movement |
Rotating |
| Emergency mode |
Y |
| Security leve |
Medium |
| MCBF |
2 million |
| Options/Accessories |
Counter, SUS316 Cabinet and Lid, Remote Contro |
